• High efficiency filtration in HVAC
• Designed to maximize dust holding capacity by increasing filtration area.
• Used in multi stage filtration alongwith panel or pleated filter in front to extend life.
• Configurable with a range of sizes, efficiencies, and pocket counts.
| Classification | EU5-EU9; M5-F9 (EN779), MERV 9-13 (ASHRAE 52.2) ePm 10-ePm2.5 (ISO 16890) |
| Efficiency | |
| Temperature | 75°C maximum s |
| Applications | Residential, commercial, industrial, airports, schools and universities, train stations, food and beverage, life sciences, office buildings, shopping centers, pharmaceutical, hospitals and healthcare setups. |
| Frame Type | GI/ Aluminium extruded anodized/SS |
| Media | Non-woven water resistant synthetic or Microfine Glass Fibre |
| Sealant | PU Gasket Neoprene |
Type |
Type |
Size |
Number Of bags |
Filtration Area |
||
Flange |
|
Height |
Width |
Depth |
|
|
EU5-EU9 |
590 |
590 |
590 |
6 |
3.9 |
|
EU5-EU9 |
610 |
610 |
500 |
6 |
4.0 |
|
EU5-EU9 |
610 |
610 |
590 |
6 |
4.3 |
|
|
EU5-EU9 |
610 |
610 |
760 |
6 |
5.5 |
